Ultra-thin down-pressed welded copper bottom
Product size: 97*102*48mm
Net weight of heat sink: 290g
Heat pipe: Φ6mm x 5pcs
Fan size: 92*92*13mm
Voltage: 12V
Power consumption: 0.48-5.16W
Bearing: FDB
Speed: 3500RPM±10%
Air volume: 56.8CFM
Air pressure: 1.98mmH2O
Noise: 33.7dBA
Terminal: 2510-4pin, PWM
INTEL1700/115x
TDP: 135W
The total height of the radiator is only 48mm, and the overall surface is nickel-plated, which is beautiful. It uses five copper tubes and a copper block welded at the bottom. The heat dissipation effect can reach 135-145W; the fan uses a one-piece frame, ultra-quiet 11 blades, and a straight-locking screw type for easy installation.
